Feature
parameter
|
Truck |
Drive mode |
6×4 |
|
|
Chassis |
DFL1250A8 |
||
|
Engine |
Model |
Cummins C245 33 |
|
|
Type |
136/2500 |
||
|
Power/Displacement(Kw/ml) |
180KW/8300 |
||
|
Type of fuel |
Diesel |
||
|
Oil Consumption(km/L) |
22.4 |
||
|
Tyre |
Size |
10.00-20,10.00R20 |
|
|
Gear Box |
Mechanical 6 speed gear box |
||
|
Steering |
Power assist steering |
||
|
Air conditioner |
A/C |
||
|
Dimensions |
Overall dimension (mm) |
9600×2500×3480 |
|
|
Wheel base (mm) |
4350+1300 |
||
|
Front/Rear tread(mm) |
1986/1860 |
||
|
Performance |
Max. speed(Km/h) |
90 |
|
|
App./Dep. angel (°) |
20/15 |
||
|
Max. gradability (%) |
30 |
||
|
Min.turning diameter(m) |
18 |
||
|
Min.ground clearance(mm) |
240 |
||
|
Mass |
Payload (Kg) |
22000 |
|
|
Curb weight(Kg) |
12805 |
||
|
G.V.W (Kg) |
35000 |
||
|
Axle Loading Weight(Kg) |
7000/18000 |
||
|
Tank |
Specfication of Tank |
Container Capacity(m³) |
18 |
|
Filling Mouth Grand Clearance(mm) |
740 |
||
|
Filling Circulation Time(s) |
20-25 |
||
|
Precompressor Load Time(s) |
18-22 |
||
|
Precompressor Lifting Time(s) |
6-9 |
||
|
Max. Compression Strength(T) |
12 |
||
|
Max.Discharge Strength(T) |
8 |
||
