Feature
parameter
| Drive mode | 6×4 | |
| Engine | Model | Cummins C270 30 |
| Type | 6-cylinder in line, turbocharging and inter cooling, mechanical injection bump, built-in EGR | |
| Max. power(Kw/rpm) | 198/2500 | |
| Max. torque(N.m/rpm) | 1025/1400 | |
| Cylinder bore ×Stroke(mm) | 107×124 | |
| Displacement(ml) | 6700 | |
| Type of fuel | Diesel | |
| Compression ratio | 17.3:1 | |
| Cab | D310-S3 | single sleeper |
| Capacity | 3 persons | |
| Gearbox | Type | 9JS119 |
| Clutch | Φ430mm | push-type diaphragm spring clutch |
| Frame H×W× T(mm) | 300×90×(8+6) | |
| Axles | Front axle(Kg) | 7000 |
| Rear axle(Kg) | 13000×2 | |
| No. of spring leaves | 8/10 | |
| Tyre | Size | 11.00R20 |
| Air conditioner | A/C | |
| Dimensions | Overall dimension(mm) | 10060×2480×3030 |
| Inner dimension(mm) | 7800×2292×2400 | |
| Wheel base(mm) | 4350+1350 | |
| Front/Rear tread(mm) | 1986, 1860/1860 | |
| App./Dep. angel (°) | 28/30 | |
| Min. ground clearance(mm) | 300 | |
| Performance | Max. speed(Km/h) | 90 |
| Mass | Payload(Kg) | 20,800 |
| Curb weight(Kg) | 9,000 | |
| G.V.W(Kg) | 29,800 | |
