Kinglong diesel City bus-Henan Tarzan Industrial Co., Ltd.

Features

01 The design of City Bus is plain rather than simple,as reflected in the fine lines. The smooth body curves contribute dynamics and vividness. The round lights offset the bold, vigorous outline of the head against the round, full contour of the tail, bringing a sense of modem beauty and simplicity.
02 Few colors are applied to the interior of City Bus, which is thus bright and fresh. The passenger-friendly spatial arrangement highlights the capaciousness and brightness. Furthermore, its complete configuration enhances the comfortableness for passengers.

Specifications

MODEL	XMQ6850G	XMQ6106G	XMQ6125AGD
LengthWidthHeight (mm)	8490×2450×3030,3140	10480×2500×3040/3190 (With air conditioner) (CNG status, with a height of 3370)	1245025503300
Wheelbase (mm)	4250	5100	6400
Front overhang/rear overhang (mm)	1840/2400	2350/3030	2570/3480
ENGINE
Brand	YUCHAI	YUCHAI	YUCHAI
Model	YC4G180-50	YC6G240-30	YC6L280-30
Emission standard	Euro V	Euro III	Euro III
Rated power (kw/rpm)	132/2300	177(240)/2200	206/2200
Rated torque(N.m/rpm)	660/1100-1400	950/1200-1500	1100/1400-1600
Displacement (L)	5.2	6.7	8.4
TRANSMISSION &CLUTCH
Transmission	Manual transmission	Manual transmission	ZF automatic transmission
AXLES
Front	DONGFENG axle	Chinese	DANA axle
Rear	DONGFENG axle	Chinese	DANA axle
SUSPENSION	Multiple-leaf spring	Leaf Spring	Air suspension, 2 air bellows in front and 4 in rear
STEERING
Steering system	Chinese	Domestic Steering gear	BOSCH power steering
Brake system
Brake system (Disc/Drum)	Front/Rear Drum	Drum Brake	Front disc and rear drum braking
Tyre	9R22.5	Domestic 10.00-20 diagonal tire	Michelin/Bridgestone tubeless tyres 295/80R22.5,Middle East spec
ABS	ABS	No	WABCO ABS
Body
Doors	Front inner-swing doors,two of the middle inner-swing door	Front and rear double inner-swinging door	Aluminum alloy swing doors
Side Windows	Aluminium alloy sliding windows	Enclosed toughened side windows (Left and right last pull-push window)	Underneath closed and upside sliding glasses
SEATS
Driver	Mechanical damping driver seat(with three-point safety belt)	Fabric cover, King Long high back, adjustable driver seat	Shock absorbing high back adjustable seat, 3 point safely belt
Passenger	KING LONG passenger seat	Public transit bus special seat	City bus special seat
OTHER STANDARD EQUIPMENT	Flat paint,&engine cabin automatic fire extinguisher	Independent defrosting device, sun visor (one spoke), MP3/Radio player, extinguisher 2×4kg, engine compartment automatic fire extinguisher, 4 units safety hammer, exit bell	CAN instrument, engine cabin automatic fire extinguisher, metallic paint optional
