| Model | KNL5290THB 37-5RZ | ||
| Item | Unit | Value | |
| Pumping system | Max. Theor. Output(high/low pressure) | m3/h | 66/111 |
| Max. Theor. Concrete Output Pressure (high/low pressure) |
MPa | 10/6 | |
| Rated Working Pressure | MPa | 32 | |
| Pumping Frequency(high/low pressure) | min-1 | 19/32 | |
| Hopper Capacity | L | 600 | |
| Filling Height | mm | 1400 | |
| Hydraulic System Type | Open Loop | ||
| Distribution Valve | S-valve | ||
| Oil Cylinder Dia.×Stroke | mm | φ125×1400 | |
| Concrete Cylinder Dia.×Stroke | mm | φ230×1400 | |
| Hydraulic Oil Cooling | Air cooling | ||
| Recommended Concrete Slump | cm | 12~23 | |
| Max. Aggregate Dimension | mm | 40 | |
| Placing boom | Structure Type | 37-5RZ | |
| Max. Placing Depth | m | 36.1 | |
| Horizontal Placing Radius | m | 32.6 | |
| Placing Depth | m | 25.5 | |
| Slewing Angle | ±270° | ||
| Pipe Diameter | mm | 125 | |
| End Hose Length | mm | 3000 | |
| Min. Height of Opening Placing Boom | mm | 9000 | |
| Outriggers Span (Front×Rear×Side) | mm | 6140×7606×8446 | |
| Others | Lubrication Mode | Manual and Hydraulic dual-use | |
| Oil Tank Volume | L | 500 | |
| Control Mode | Manual and Remote Control | ||
| Maximum Water Pressure | MPa | 0.8 | |
| Water Tank Volume | L | 400 | |
| Concrete Pipe Cleaning Mode | Water Cleaning / Dry Cleaning | ||
| Total weight | t | 23.42 | |
